AGV/AMR Automation Equipment Overview
Select Suitable AGV/AMR Equipment Based on Transport Flow
Explore AGV / AMR equipment for pallet transport, stacking, narrow aisle transport and towing applications. Equipment selection should not be based on model type alone. It is also important to evaluate on-site transport flow, space conditions and system integration requirements.
01
Transport Task Review
Review on-site transport tasks such as pallet transport, stacking, long-distance towing and line-side replenishment.
02
Space Condition Check
Check aisle width, turning radius, lift height, indoor/outdoor environment and other space conditions required for stable operation.
03
System Integration Review
Review integration requirements with WMS, MES, RCS and on-site equipment, as well as task dispatching, transport tracking and status feedback.
04
Transport Flow Design
Build an operable transport flow that connects transport tasks, inventory information and on-site operations, while supporting future expansion and adjustment.
AGV/AMR Product Series Quick Guide
Click to quickly view product specifications and initially identify suitable AGV/AMR equipment types based on racking height, aisle width, transport distance, carrier type and operating scenario.
AGV Forklift Series
AGV/AMR Product Series Overview
NTT DATA provides a range of AGV/AMR equipment options, including pallet truck AGVs, pallet stacker AGVs, reach truck AGVs, counterbalance AGVs, automated towing vehicles and underride/lifting AMRs. Companies can select suitable AGV/AMR equipment based on material type, transport distance, aisle width, lifting height and operating environment.
NDT Series｜Pallet Truck AGV
Designed for horizontal pallet transport, raw material transfer and finished goods movement. Suitable for indoor medium- to long-distance transport, production line replenishment, warehouse inbound/outbound transfer and similar material handling scenarios.
Major Features
- Suitable for high-load pallet transport
- Supports automatic adjustment and space detection
- Suitable for planned routes and longer-distance horizontal transport
- Can be integrated with WMS and MES for task dispatching and status feedback
Key Specifications
Max. Load：2,000 kg
Max. Lift Height：125 mm
Max. Speed：1.6 m/s
Positioning：IMU + Vision
Typical Applications：Pallet handling, horizontal transport, inbound/outbound transfer
Contact Us
View Lineup Major Features
- Suitable for pallet stacking, storage and retrieval
- Supports automatic adjustment and load position detection
- Helps improve material handling efficiency
- Can be integrated with WMS and MES for task dispatching and status feedback
Key Specifications
Max. Load：1,400 / 1,600 kg
Max. Lift Height：4,144–4,244 mm
Max. Speed：1.6 m/s
Positioning：IMU + Vision
Typical Applications：Pallet stacking, warehouse inbound/outbound transfer, line-side replenishment
NDL Series｜Pallet Stacker AGV
Designed for pallet stacking, storage and retrieval, and line-side material replenishment. Suitable for warehouse inbound/outbound transfer, line-side material flow and operations that require higher handling efficiency and stacking accuracy.
NDR Series｜Reach Truck AGV
Designed for high-bay storage, narrow aisle operations and high-position pallet access. Suitable for storage/retrieval, pallet stacking and warehouse operations that require higher space utilization and precise positioning.
Major Features
- Suitable for high-bay storage and high-level pallet access
- Supports automatic adjustment and load position detection
- Recognizes rack beams, available space and storage locations
- Can be integrated with WMS and MES for task dispatching and status feedback
Key Specifications
Max. Load：1,400 / 1,600 kg
Max. Lift Height：8,555–9,455 mm
Max. Speed：2.0 m/s
Positioning：IMU + Vision
Typical Applications：High-bay storage, high-level pallet access, narrow aisle operations
Major Features
- Suitable for narrow aisles and limited-space transport
- Supports automatic adjustment and load position detection
- Helps reduce aisle width requirements
- Suitable for low-level stacking, line-side replenishment and warehouse transfer
Key Specifications
Max. Load：1,400 kg
Max. Lift Height：1,600 mm
Max. Speed：1.0 m/s loaded, 1.3 m/s unloaded
Positioning：IMU + Vision
Typical Applications：Narrow aisle transport, low-level stacking, line-side replenishment
NDSL Series｜SLIM Stacker AGV
Designed for pallet handling and low-level stacking in limited storage space, narrow aisles or compact operating areas. Its compact vehicle design helps improve aisle utilization and material handling flexibility.
NDE / NDP Series｜Counterbalance AGV
Designed for indoor and outdoor sites, large materials and heavy-load pallet handling. Suitable for site-to-site transfer, warehouse inbound/outbound operations, line-side replenishment and stacking tasks to improve heavy-load transport efficiency and operational safety.
Major Features
- Suitable for indoor/outdoor sites and heavy-load transport
- Supports pallet handling, inbound/outbound transfer and stacking tasks
- Compatible with various load carriers and handling attachments
- Can be integrated with WMS and MES for task dispatching and status feedback
Key Specifications
Max. Load：1,500–2,000 kg
Max. Lift Height：4,500 mm
Max. Speed：1.3–2.7 m/s
Positioning / Sensing：IMU + Vision / 3D hybrid sensors
Typical Applications：Indoor/outdoor heavy-load transport, pallet handling, inbound/outbound transfer
Major Features
- Suitable for long-distance and multi-stop towing
- Supports towing of multiple carts or trolleys
- Suitable for indoor/outdoor heavy-load logistics transport
- Can be integrated with WMS and MES for task dispatching and status feedback
Key Specifications
Max. Towing Load：6,000 kg
Max. Speed：2.0 m/s
Positioning：IMU + Vision
Stopping Accuracy：±10 mm / ±0.5°
Typical Applications：Long-distance towing, cart transport, multi-stop delivery
NDQ Series｜Automated Towing Vehicle
Designed for indoor and outdoor long-distance transport, multi-stop delivery and heavy-load towing operations. Suitable for towing carts, trolleys or multiple load carriers across logistics areas to improve transport efficiency and reduce manual handling workload.
Narrow Aisle AMR
Designed for warehouse, production line and line-side material handling. With a compact design, flexible movement and high payload capacity, it can autonomously complete pallet transport tasks in narrow aisles.
Narrow Aisle｜Pallet Handling｜Line-side Replenishment
Major Features
- Suitable for frequent transport between warehouses and production lines
- Moves flexibly in narrow operating spaces
- Supports manual operation, standalone operation and fleet dispatch
- Supports precise pallet docking to improve transport stability
Key Specifications
Max. Load：1,500 kg
Max. Lift Height：205 mm
Max. Speed：1.5 m/s
Dimensions：1515 × 790 × 1860 mm
Typical Applications：Narrow aisle transport, pallet handling, line-side replenishment
Major Features
- Suitable for narrow aisles and compact storage areas
- Supports autonomous navigation and high-precision positioning
- Payload capacity up to 1,000 kg
- Suitable for multi-industry material handling and daily transport tasks
Key Specifications
Max. Load：1,000 kg
Max. Lift Height：155 mm
Max. Speed：0.7 m/s
Dimensions：1475 × 900 × 1800 mm
Typical Applications：Compact storage, narrow aisle transport, line-side transfer
Compact Narrow Aisle AMR
Designed for warehouses and manufacturing sites with limited space. It supports autonomous navigation and transport in narrow aisles, helping improve material movement efficiency.
Compact Storage｜Narrow Aisle Transport｜Line-side Transfer
Underride Fork AMR
Designed for high-density storage and line-side material handling. It can move under load carriers for automated fork pickup and transfer, supporting various pallet, rack and trolley types.
High-density Storage｜Pallet Transport｜Trolley Transfer
Major Features
- Suitable for high-density storage and line-side transport
- Supports open/closed pallets and various load carriers
- Adapts to production line changes and warehouse layout adjustments
- Helps improve warehouse space utilization
Key Specifications
Max. Load：1,500 kg
Max. Lift Height：355 mm
Max. Speed：1.5 m/s
Dimensions：1335 × 1130 × 1800 mm
Typical Applications：High-density storage, pallet transport, trolley transfer
Major Features
- Suitable for long-distance and heavy-load towing
- Supports automatic coupling and decoupling
- Can tow multiple carts, trolleys or trailers for material transfer
- High-precision positioning supports smooth docking and transport efficiency
Key Specifications
Max. Towing Load：5,000 kg
Max. Speed：2.0 m/s
Dimensions：1845 × 997 × 1850 mm
Operation Mode：Automatic towing, coupling and decoupling
Typical Applications：Long-distance towing, cart transport, multi-stop delivery
Towing AMR
Designed for long-distance towing of carts, trolleys and trailers. With strong towing capability and stable driving performance, it supports automatic coupling and decoupling, helping improve safe and efficient material transport.
Long-distance Towing｜Cart Transport｜Multi-stop Delivery
Warehouse Automation Applications
Warehouse Automation Applications
For high-bay picking, bin storage and retrieval, overhead transport, put wall or ESL applications, explore our automated storage solution.
AGV/AMR System Integration
Beyond Equipment Selection
Connect AGV/AMR equipment with WMS, MES, RCS and on-site equipment, and plan task dispatching, transport tracking and status feedback as one workflow.
Need Help Selecting Suitable AGV/AMR Equipment?
Different sites have different requirements for transport distance, payload, aisle width, lifting height, load carrier type and system integration. NTT DATA helps companies evaluate suitable AGV/AMR equipment and integration approaches based on site processes and operating conditions.
